Double Mat Lifter - 502061

Product Description

To ensure balanced operation, the Double Mat Lifter features a three cable system. Standard lifter, load bar, and slings support two standard 42' x 42' (12.80 m x 12.80 m) wrestling mats (weighing approximately 1 lb/ft²). Mats may be one-piece or in sections placed end to end. A custom integrated motion alarm system automatically sounds when the lifter is in motion. In case of a power outage, an emergency lowering manual override brake is included. Motors, drive assembly, and all control mechanisms are encased in a fire proof safety cover.

Product Specs

  • Standard sling color is black; other colors are available by special request.
  • Supports two 42’ x 42’ (1,280 cm x 1,280 cm) wrestling mats, weighing approximately 1 lb/ft² (4.88 kg/m²) with a 5-to-1 safety ratio.
  • Available with choice of over-under or side-by-side sling configuration.
  • Unit weight excluding mats is approximately 1,750 lb (793.79 kg).
  • Lifting and lowering speed is approximately 10 feet per minute.
  • Three 5”-16" (127 mm - 406 mm), 7 x 19 lifting cables.
  • Complete system independently tested to 17,500 lb (7,938.87 kg).
  • Optional wall brackets and travel kits available.
