Premier XL Electric Projection Screen

Now available in new 21:9 format.

Ideal for conference rooms, classrooms, or home theaters, the economical Premier XL wall- or ceiling-mounted electric projection screen includes a tab-tensioned viewing surface. Draper tab-tensioned screens have perfectly flat viewing surfaces and RF welded tabs for a more durable seal. Premier XL comes housed in a fabricated extruded aluminum case with a curved front and L-shaped back/top cover with an attractive black finish.


Product Specs

  • Case dimensions: 6-3/4" high x 6-3/4" deep (17 cm x 17 cm). Housed in fabricated extruded aluminum with a curved front and L-shaped back/top cover with black finish.
  • For smaller sizes the Premier is functionally similar to the Premier XL and available in sizes through 16' (488 cm) wide.
  • Maximum image width up to 16’ (488 cm) wide, depending on surface selection.
  • Image area fully framed with black. Standard 12" (30 cm) black drop at top of viewing area. Optional extra drop available which may increase case length.
  • Optional wall- or ceiling-mounting brackets for added flexibility.
  • Optional Plug & Play with built-in low-voltage controller (LP) or with built-in quiet, low-voltage controller (QLP). Screens over 119" diagonal on 16:9 format on this screen cannot use QLP.
  • Includes one 110-120V, 3-position switch (standard). Other control options are available.
  • Custom sizes available.
  • UL Listed.

Sizes, Part Numbers & Prices

Surface Material:  Image Format:  Diagonal (Image area): Voltage: Motor Options:  Unit of measure:
Part number:101804
Surface material:Matt White XT1000VB
Image Format:16:10
Diagonal size:189"
Image/Viewable area:100" x 160"
Image/Viewable area 2:
Overall size:
Case length:183 1/8"
Height range:
Closed dimensions:
Product weight:194 pounds
Shipping weight:415 pounds
U.S. Retail Price:$5596




Draper manufactures custom size screens to meet your specification. Virtually any size within the maximum shown for a given model is available. Please call for pricing on special sizes.

Related Products & Accessories

CONTROLS for this screen.
Premier
Targa XL
*Valid in the United States and Canada. Our warranty information can be found here.
