Access M Manual Projection Screen

Ceiling-Recessed Manual Projection Screen with Bottom Panel for Easy Maintenance

Maximize space in boardrooms, training rooms, and classrooms with the ceiling-recessed Access M projection screen. Ceiling-recessed screens are hidden from view when not in use providing complete concealment. Free-hanging screens maintain flatness due to the weight of the viewing surface and bottom dowel. Case includes a bottom access panel door for easy service and maintenance.


Product Specs

  • Case dimensions are 7-3/8" high x 8-1/16" deep (19 cm x 20 cm), includes trim flange.
  • Maximum image width up to 12' (366 cm) wide.
  • NTSC, HDTV AND 16:10 format have image area framed with black on all fours sides. Black side borders are available on request for AV format Screens.
  • Spring-roller operated front projection screen provides a quiet, smooth operation.
  • Adjustable or removable hoisting brackets included for easy lifting during installation.
  • Sliding brackets inside case accommodate different size screens.
  • Bottom access panel door is detachable.
  • Optional, removable aluminum operating pole available in lengths of 4' or 6' (122 cm or 183 cm).
  • Sizes above 70" (178 cm) in height include a pull cord.
  • White case standard, black available.
  • Custom sizes available.

Sizes, Part Numbers & Prices

Surface Material:  Image Format:  Diagonal (Image area): Unit of measure:
Part number:197065
Surface material:Matt White XT1000E
Image Format:16:10
Diagonal size:137"
Image/Viewable area:72 1/2" x 116"
Overall size:76 1/2" x 120"
Case length:126"
Product weight:72 pounds
Shipping weight:87 pounds
U.S. Retail Price:$2310




Draper manufactures custom size screens to meet your specification. Virtually any size within the maximum shown for a given model is available. Please call for pricing on special sizes.

Related Products & Accessories

ACCESSORIES for this screen.
Access E
Access V
Case: Access Case
