Skylight Motorized FlexShade

Motorized Shade for Skylights

Skylight Motorized FlexShade window shade provides indoor solar control and UV protection from overhead sunlight generated by an unprotected skylight. Controlling solar heat gain and glare help keep indoor spaces cooler. It provides a more comfortable workspace environment, as well as protecting employees, furnishings, and assets.


Product Specs

  • Available in sizes up to 6' wide x 8' high (183 cm x 244 cm), depending on fabric selection.
  • Maximum unsupported width of 36" (91 cm).
  • Units wider than 36” (91 cm) require vinyl-clad aircraft support cables.
  • Battens included to ensure flattest surface possible.
  • Install Skylight on any angle, with rollers level and parallel.
  • Venting space between shade and glass recommended.
  • Perimeter support angles simplify installation.
  • Side flanges prevent direct light leaks.
  • Recessed or surface mount install.
  • Continuous cable provides self-adjusting equalization of tension.
  • Hardware finish choices: clear anodized (standard), black, white, ivory, or charcoal bronze. Custom powder coat colors available.
  • Select mesh fabric for light filtration or SunBloc for opacity.
  • Available with Standard AC, RTS Radio Technology Somfy AC, 485 AC, or IntelliFlex I/O AC Controls.
  • Product designed for interior use.

ANSI/WCMA A100.1-2022 Child Safety Standard

Effective June 1, 2024, in compliance with the updated ANSI/WCMA A100.1-2022 child safety standard, all Draper window shades operated by a bead chain will be furnished with a tensioned hold-down device that is permanently attached and partially disables the product if not installed correctly. This hold-down should be installed with tension on the chain.

All bead chain operated window shades will include:

  • Permanently installed spring-loaded tensioned hold-down device
  • Approved permanent warning label attached
  • Approved mechanical fasteners for the tension device included. Screws provided are not suitable for all mounting surfaces. The installer is responsible for secure mounting using appropriate hardware for the site conditions. Consult with contractors and builders as needed.

If the tension device is not installed with appropriate tension on the bead chain, the shade will be rendered partially inoperable. If installed properly, the tension device will prevent the creation of a hazardous loop and will maintain tension on the bead chain.

Approved permanent warning label

Learn more about the new child safety standard

At the link below, you can see more information about the new child safety standard, mounting methods for the tensioned hold-down device, alternatives to bead chain products, and more.

Click here for more information
Tensioned hold-down device
